Vatech Green X CBCT
Make: Vatech
Model: Green X
Warranty: 5 Years
NEW GREEN INNOVATION
- 4-IN-1 DIGITAL X-RAY IMAGING SYSTEM
[PANO / CEPH / CBCT / MODEL SCAN] - MULTI FOV SELECTION
- GREEN SCAN TIME
- ENDO MODE WITH HIGH RESOLUTION
- INSIGHT 2.0 FEATURE
- 3D SCANNING FOR MODEL
4-IN-1 DIGITAL X-RAY IMAGING SYSTEM
Green X is an advanced 4-in-1 digital x-ray imaging system that incorporates Pano, Ceph (optional), CBCT, and Model Scan. With Vatech’s extensive experience in the dental imaging field, the Green X provides high-quality images with lower radiation by combining image processing. This will improve your diagnostic accuracy and lead to increased treatment planning and patient satisfaction.
MULTI FOV SELECTION
Green X offers a range of selectable fields of view. The Multi FOV option allows users to select the optimum FOV mode while minimizing exposure to areas that are not in the region of interest. The selection includes the following FOV sizes for diagnostic needs: 16×9, 12×9, 8×9, 8×5, 5×5 and 4×4. These options cover the full arch region, sinus and left/right TMJ, and suits most oral surgery cases and multiple implant surgeries.
Due to its scan time, the Green X minimizes motion artefact and enables faster work flow. It produces superb diagnostic images, which will be a source of pride for any dental practice. Focusing on the highest quality of patient care, Vatech strives to improve the health and safety of your patients.
ENDO MODE WITH HIGH RESOLUTION
With its 4cm x 4cm volume mode and 49.5 micron voxel size, the Endo mode will optimize treatment of highly-focused regions of interest. It is ideal for endodontic use because the dentist is able to achieve an extraordinary image in a high-resolution voxel size.
INSIGHT 2.0 FEATURE
The Insight Pan is capable of taking a multi-layered panoramic image, called an Insight Pan, which provides a unique in-depth look across a single focal trough. Insight 2.0 has an upgraded free FOV feature so you will be able to capture just the area of interest.
3D SCANNING FOR MODEL
3D model scan enables users to store plasters as digital models.
Specifications:
Function: CT + PANO + CEPH + Model Scan
Focal Spot Size: 0.5mm (IEC 60336)
CT FOV Size: 16x9cm – 4×4, 5×5, 8×5, 8×8, 12×9, 16×9
Voxel Size: 4×4 = 0.05mm, 5×5 = 0.08mm / 0.12mm, 8×5 / 8×8 = 0.12mm / 0.2mm, 12×9 / 16×9 = 0.2mm / 0.3mm
Scan Time: PANO = 4.0 sec/ 14.1 sec, CEPH = 1.9 sec/ 4.9 sec, CBCT = 2.9 sec/ 9.0 sec
Grey Scale: 14 Bit
Tube Voltage/ Current: 60-99 kVp / 1-16mA
Weight: With CEPH 187.9kg / Without CEPH 162.9kg
Dimensions: With CEPH 1905.5mm (L) x 1374.9mm (W) x 2315.4mm (H) / Without CEPH 1085.0mm (L) x 1343.5mm (W) x 2315.4mm (H)
*An additional 3 inches (76.2mm) of space is required behind the unit for wall mount bracket installation
(mandatory unless there is a base mount installation).
